Handheld XRF analyzer for ROHS

1. High-speed processing chip, advanced algorithm and high-responsive software, resulting in even faster analysis.
2. High-performance X-ray Tube, Ultra-high Resolution Detector combined with Digital Multi-channel Processing Technology, yielding super-high detection resolution.
3. Indicator lights flash on both sides for safety purposes during measurement, i.e., the built-in double beam technology will automatically sense whether there is a sample at the measurement window.
4. TrueX's new algorithm optimizes the spectral resolution, so lower detection limits can be achieved, which are comparable with even large-scale lab instruments
5. TrueX Ultra-short optical™ path design can significantly improve light element excitation effects, without the fall/fill condition.
6. CPU running over 1 GB which make instrument working faster
7. 32GB memory which other companies can't come to this
8. Full completely Preloaded Grade Library such as industry Grade Library(petroleum Grade Library, Precious Metals Grade Library, steel Grade Library, tooling Grade Library and so on) , different country Grade Library standers and also you can customize your own Grade Library.
9. I COULD service which can do the testing, maintenance and repaired through remote control.

Technical parameters

Weight	1.6Kg(with battery)
Dimensions	254 x 79 x 280 mm(L x W x H).
Excitation source	50KV/200μA maximum pipe pressure pipe flow can be adjusted freely,Agtarget (standard),Au,W,Rh target(optional).
Detector	BOOST Si-PIN detector/SDD detector
Range of detection	All elements between Mg and U.
Display system	Industrial resistive touch screen with screen size of 4.3". Multiple languages including English and Chinese. And it automatically adjusts display brightness according to the environment brightness.
Heat dissipation	Equipped with a dedicated T-shaped radiator to dissipate the heat;no need to wait for cooling of detector time again.
System Processor	The Android 4.2 operating system/80MHZ ADC digitalpulse processor/4096 MCA channel , 32GB memory
Data storage	Built-in 32gb memory, 300,000 spectral data and spectrumcan be stored
Operating Temperature	-20℃~+50℃
Operating Humidity	≤90%Limit of Detection: PPM
Safety	Built-in double beam technology can automatically sense whether there is a sample at the measurement window. This is also a safety and protection feature.
Power supply system	Intelligent battery management through MSBUS bus, real-time monitoring of the residual capacity of battery and backup battery. The battery complies with air transport regulations of dangerous goods. A single battery can last 8 hours.
